Modern Jali Design Ideas for Homes & Building Elevations
The jali solves three problems at once. It moves air through a building, filters harsh sunlight into something softer and patterned, and gives privacy without shutting a space in — all from a single perforated screen. That combination is why it has stayed relevant across centuries of South Asian architecture, documented in the Archnet collection maintained by MIT and the Aga Khan Trust for Culture.
Today it appears in facades, boundary walls, staircase screens, courtyards and terrace partitions — anywhere a solid wall would feel closed and glass would feel exposed. The material has changed; precast concrete and GFRC have largely replaced the carved sandstone of Mughal-era screens. The logic hasn’t. Below are nine patterns from the Cara Tiles breeze block range, grouped by visual character.
Geometric Jali Designs
Clean, repeating, architectural. These suit minimalist and contemporary elevations where the screen should read as rhythm rather than ornament.
Cube Jali Design
The most reductive pattern in the range — a recessed square aperture, repeated. Openness is high, so airflow is excellent and close-range privacy minimal. Cube reads as texture from a distance and a clean grid up close: a strong choice for long boundary walls and minimalist facades that should feel light rather than decorative. 8″ × 8″ × 100mm.
Box Jali Design
Where Cube is one square, Box nests squares within squares at varying depths — a more intricate grid with visible internal shadow. The layered apertures cut sightlines better than Cube while keeping airflow high. Box also takes two-tone installation exceptionally well: alternating charcoal and ivory turns a functional screen into a graphic feature wall. 8″ × 8″ × 100mm.
Arrow Jali Design
Triangular apertures bring diagonal movement into an orthogonal wall — Arrow breaks the monotony of a large screen without adding ornament. The angled faces catch light differently through the day, so the wall shifts between morning and afternoon. Suits terraces and balcony screens where a flat grid would feel static. 8″ × 8″ × 100mm.
Tulip Jali Design
The most sculptural of the geometric group — each block is faceted into pyramidal quadrants, giving genuine three-dimensional relief rather than a flat face with holes in it. Openness is lower than Cube or Box, so pick it where texture and shadow depth matter more than airflow. Strong in mixed grey-and-white layouts. 8″ × 8″ × 100mm.
Organic Jali Designs
Curved and floral geometries. These soften a facade and sit comfortably alongside traditional and transitional architecture.
Leaf Jali Design
A subtle curved motif inside a squared frame — quieter than Tulip, less austere than Cube. The framed format performs best in checkerboard two-tone layouts, where alternating colours produce a pronounced graphic across the elevation. The middle option when a full floral screen is too much. 8″ × 8″ × 100mm.
Statement Jali Designs
Larger, more visually dominant patterns for elevations where the screen is the design.
Vista Jali Design
The most complex pattern in the range — concentric squares crossed by diagonals, giving multiple aperture sizes within one block. Vista holds attention at close range in a way simpler grids don’t, making it right for entrance walls, feature panels and screens people stand near. Its density also gives noticeably better privacy than Cube or Box. 8″ × 8″ × 100mm.
All patterns come in Ivory, Grey, Terracotta, Charcoal and Antique. Full dimensions and colour references are in the 2026 catalogue.
How to Choose a Jali Design
Privacy. Vista and Cork block sightlines well; open grids like Cube barely do at close range. A 100mm block screens far better at an angle than head-on.
Airflow. Higher open area means more cross-ventilation. If the jali is doing climatic work, favour the open patterns.
Daylight. Denser apertures produce fine dappling indoors; larger openings throw bolder shapes that move through the day.
Scale and viewing distance. Vista and Tulip reward close viewing but blur into grey texture from across a street. Cube and Arrow hold their form at distance.
Surrounding elevation. A busy facade needs a quiet screen; a plain one carries a statement pattern. Jali screens are non-load-bearing and need proper framing on tall or wide runs.
Where Can Jali Be Used?
- Front elevation and facade feature panels, often paired with elevation tiles or FlexiClad cladding
- Boundary and compound walls
- Staircase and stairwell screens
- Courtyards and light wells
- Terraces and roof gardens
- Balcony railings and privacy screens
- Commercial facades, restaurants and hospitality interiors
- Internal partitions and room dividers
Jali, Breeze Block or GFRC Screen?
The terms overlap, but the products aren’t interchangeable.
Jali is the term for any perforated screen, whatever the material. Breeze blocks are the precast concrete units above — modular 8″ × 8″ × 100mm pieces stacked into a screen, suited to walls and repeating patterns. GFRC Netting is glass-fibre-reinforced concrete cast in thin panels up to 4′ × 8′ and as fine as 25–30mm, holding intricate detail at low weight — Cara’s Muslim, Minar, Mehrab and Wing patterns, for window infills and mosque facades. More in our guide to the benefits of GFRC.
Rule of thumb: blocks for walls and repetition, GFRC panels for detail and large openings.
Frequently Asked Questions
Which jali design is best for a house exterior? For modern minimalist facades, Cube or Arrow. For elevations needing warmth or a more traditional character, Tulip or Leaf. For an entrance or feature wall meant to be noticed, Vista.
Does jali provide privacy? Partially — it depends on pattern and viewing angle. Vista and Cork restrict sightlines significantly; open grids like Cube provide limited close-range privacy. The 100mm depth means every pattern screens better at an angle than head-on.
Do jali blocks improve ventilation? Yes. Perforated screens allow cross-ventilation while shading the wall behind them, which is why they remain a passive-cooling element rather than a purely decorative one. For roof-level heat control, see our guide to roof heat proofing in Pakistan.
Where can concrete jali be used? Front elevations, boundary walls, staircase screens, courtyards, terraces, balconies, commercial facades and internal partitions. Mesh Breeze Blocks additionally suit kitchens and healthcare or food-service settings requiring insect exclusion.
Explore the full Cara Tiles breeze block range — nine jali patterns in five colours, plus GFRC netting panels for larger, more intricate applications. Architectural concrete in Pakistan since 2006.
